TUMBLE DRYER
- GZ series standalone auto dryers from Sea-lion are used to prepare various types of garments for the ironing and folders finishing.
- Designed to have the perfect balance of CFM airflow and heat transfer for optimal drying.
- Fitted with an ultra-smooth and durable 304 grade mirror Stainless Steel drum to protect goods.
- The microprocessor control is simple to use and features programmable time and temperature settings.
- A reversing motor system gently tumbles the goods in both directions to prevent tangling.
- Access to the lower lint screen panel is simple making quick work for filter maintenance.
- The large diameter of the door opening on our tumble dryers ensures easy loading and unloading. For maximum accessibility, the door opens to nearly 180°. The door is provided with a safety switch that stops the machine when the door is open. The door can be opened any time during operation for safety. While the door gap excesses 50 mm, the machine will stop to ensure the energy is not wasted through the gap.
- Loading door features a tempered glass window which allows for a visual check of the goods during the cycle. The door opening is oversized to allow for easy loading and unloading.
- Protective 304 grade Stainless Steel cabinet.
- A special & unique feature of our drier is a lint drawer located in front of the exhaust fan. This prevents lint from clogging the fan, which causes damaging vibration. This also eliminates the need for costly external lint collectors and reduces lint fire concerns. The lint filter is efficient and provides a good airflow that reduces the energy consumption.
- Available with gas burner (GRZ), steam (GZZ) or electric (GDZ) heating.
Air Flow & Heating Balanced

Efficiency

Energy
Saving

Easy
Maintenance

Temperature
Control
TECHNICAL SPECIFICATIONS
Unit | Description | GZZ(GDZ)-15 | GZZ-S-400 | GZZ(GDZ)-50 | GZZ(GDZ)-100 | GZZ-100Q |
---|---|---|---|---|---|---|
kg | Rated capacity | 15 | 25 | 50 | 100 | 100 |
mm | Inner drum length | 780 × 650 | 1160 × 955 | 1460 × 1180 | 1460 × 1180 | |
V/P/Hz | Power supply | 380/3/50 | 380/3/50 | 380/3/50 | 380/3/50 | 380/3/50 |
kW | Main motor power | 0.55 | 0.75 | 1.5 | 3 | 3 |
kW | Fan | 0.37 | 0.55 | 1.5 | 2 x 1.5 | 2 x 1.5 |
rpm | Drum speed | 45 | 32 | 30 | 30 | |
MPa | Steam pressure | 0.5-0.6 | 0.5-0.6 | 0.5-0.6 | 0.5-0.6 | 0.5-0.6 |
DN | Steam pipe/DM | 20 | 20 | 25 | 25 | 40 |
DN | Drain pipe/DM | 15 | 20 | 25 | 25 | 25 |
kg | Steam Cons/cycle | 18-25 | 25-30 | 50-60 | 100-120 | 100-120 |
kw | Power Cons/cycle | steam 0.5 / electric | steam 0.86 / electric | steam 1.8 / electric | steam 3.5 / electric | / |
kw | Heater power | 14.4 | / (17) | / (432) | / (80) | / |
mm | Air Exhaust/DM | 167 x 147 | 240 x 260 | 280 x 347 | 330 x 400 | 333 x 403 |
mm | Dimension(L/W/H) | 1150/870/1450 | 1192/1015/1694 | 1576/1282/2072 | 1996/1602/2344 | 2100/1600/2560 |
kg | Weight | 280/310 | 360 | 725 (765) | 1450 (1500) | 1548 |
GRZ-25 | 25 | 930/800 | 380/3/50 | 0.75 | 0.55 | .005-.02 | 15 | 0.5 | 1.2 | 1371/1043/178 | 596 |
GRZ-50 | 50 | 1160/955 | 380/3/50 | 1.5 | 1.5 | .005-.02 | 15 | 1.8 | 4.5 | 1576/1282/207 | 800 |
GRZ-100 | 100 | 1460/1236 | 380/3/50 | 3 | 2/1.5 | .005-.02 | 20 | 3.2 | 3.2 | 1996/1602/262 | 1500 |
