AUTOMATIC FEEDER
- Sea-lion spreader feeders make quick work of preparing linens to be properly positioned for the ironer or folder.
- Available in three and four stations, ZBQ series spreader feeders provide high efficiency and require less labour to process goods. Models
- Models can spread a variety of flatwork items up to 130 inches.
- Innovative clamp design is robust and need only latch onto corners to position flatwork linens on the belts. For accuracy a positioning servo motor assures a repeatable process and strong vacuum airflow for suction holds the flatwork securely against the belts maintaining the desired position for the ironer.
- For convenient measurement of worker productivity, each station is outfitted with a simple, digital counting display to calculate items processed.
- No need to move the machine for small items because the output table can be easily adjusted in and out automatically.
- Four stations model features moveable loading station to allow for feeding of small items from front of machine.
- Multi-lingual full colour touch screen control features 20 programs and can be easily networked to the ironer line.
- Intelligent rail design option facilitates production bottlenecks by preparing and holding linens to be processed.
Item Name | Unit | ZBQ3500-IV-H |
---|---|---|
Power Supply | V/Hz/P | 380/50/3 |
Rated Power | kw | 18.35 |
Wire Diameter | mm² | 6 |
Power Consumption/hr | kw.h | 12 |
Compressed Air Pressure | Mpa | 0.6-0.7 |
Compressed Air Inlet | mm | Φ16 |
Compressed Air Consumption | L/min | 110 |
Speed | m/min | 0-50 |
Working Width | mm | <=3500 |
Dimension (L/W/H) | mm | 5290/2920/2480 |
Machine Weight | kg | 5400 |
